Prysmian Group 01311.46.01, 18 3C SJOOW Cable 300V 90C Black Jacket

Part Number: 01311.46.01

Prysmian Group 01311.46.01 is an 18 AWG, 3 Conductor SJOOW portable cord designed for flexible power and control applications. It features Stranded Bare Copper Conductors with EPR-Ethylene Propylene Rubber Insulation and a durable CPE Chlorinated Polyethylene black Jacket. This Cable is Unshielded, RoHS compliant, and built to UL/CSA standards. Voltage Rating is 300V OR 300/500V with a 90C Temperature Rating.

Cable Construction:

• Product Type: SJOOW
• Number Of Conductors: 3 Conductor
• Conductor Size: 18 AWG
• Conductor Material: Bare Copper
• Conductor Type: Stranded
• Ground Wires: No
• Shielding: Unshielded

Materials:

• Insulation Material: EPR-Ethylene Propylene Rubber
• Jacket Material: CPE Chlorinated PolyethyleneJacket Color: Black

Ratings & Compliance:

• Temperature Rating: 90C
• Voltage Range: 300V OR 300/500V
• Standards: UL/CSA
• RoHS Compliant: Yes
