Prysmian Group 02301.R5.02, 18 2C TYPE SPT-1 White Jacket 300V 60C
SKU:02301.R5.02
● In stock
ft
Description
Part Number: 02301.R5.02
Prysmian Group 02301.R5.02 is an 18 AWG, 2 Conductor Type SPT-1 cordage designed for reliable low-voltage power and general-purpose lead applications. It features Stranded Bare Copper Conductors with PVC-polyvinyl chloride Insulation for flexibility and dependable performance. This cord is Unshielded and does not include earth/ground wires, making it well-suited for two-Conductor designs. Rated 300V or 300/500V and compliant with UL/CSA standards, it also meets RoHS requirements.
Conductor
- Number Of Conductors: 2 Conductor
- Conductor Size: 18 AWG
- Conductor Material: Bare Copper
- Conductor Type: Stranded
- Earth/Ground Wires: No
Insulation & Construction
- Type: Type SPT-1
- Insulation Material: PVC-polyvinyl chloride
- Jacket Material: Unjacketed
- Shielding: Unshielded
- Color: White Jacket
Ratings & Compliance
- Voltage Range: 300V or 300/500V
- Temperature Rating: 60C
- Standards: UL/CSA
- RoHS Compliant: Yes
General
- Brand: Prysmian Group
- Part Number: 02301.R5.02
- Product Type: Cordage
Prysmian Group™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
