Prysmian Group 02605, Super Vu-Tron SJOOW 3C 16AWG 300V Portable Cord

Part Number: 02605

Prysmian Group 02605 Super Vu-Tron SJOOW portable cord is built for demanding flex applications, combining extra-flexible Class M Stranding with excellent cold-temperature flexibility. It features a high-visibility yellow Jacket designed to reduce scuffing and improve cleanability, while delivering strong abrasion and cut resistance. Engineered for tough environments, it is ozone-, sunlight (UV)-, weather-, water-, oil-, acid-, and chemical-resistant, with high heat and flame resistance. This 3 Conductor, 16 AWG, Unshielded cord uses Tinned Or Coated Copper Conductors with EDPM Ethylene Propylene Diene Monomer Insulation and is rated 300V OR 300/500V with UL/CSA compliance.

Key Features:

• Excellent flexibility in cold temperatures
• Lasts longer in flex applications (extra-flexible Class M Stranding)
• Integral Flexfill
• Enhanced cleanability
• Reduced scuffing
• Excellent abrasion and cut resistance
• Safety-colored, with high-visibility yellow Jacket
• TRU-Mark sequential footage Marking
• Tinned coconductors - corrosion/ oxidation-resistant

Environmental & Resistance Properties:

• Ozone-, sunlight (UV)- and weather-resistant
• Water-resistant
• Resistant to sunlight, oils, acids and chemicals
• High heat and flame resistance

Electrical & Construction Specifications:

• Product type: SJOOW
• Number Of Conductors: 3 Conductor
• Conductor Size: 16 AWG
• Conductor Type: Stranded
• Conductor Material: Tinned Or Coated Copper
• Ground wires: No
• Insulation Material: EDPM Ethylene Propylene Diene Monomer
• Shielding: Unshielded
• Voltage range: 300V OR 300/500V

Compliance:

• Standards: UL/CSA
• UL Listed and CSA Certified for in and Outdoor Use
• RoHS compliant: Yes

Prysmian Group™ and all associated trademarks are the property of their respective owners.
