Prysmian Group 02768, 14 4C Type SOOW 600V 90C Black Jacket

Part Number: 02768

Prysmian Group 02768 is a flexible Type SOOW portable cord built for demanding power and equipment applications. It features 4 Conductor Stranded Bare Copper Conductors in 14 AWG, with EPR-Ethylene Propylene Rubber Insulation and a durable CPE Chlorinated Polyethylene black Jacket. Rated 600V and 90C, this Unshielded cord is designed to meet UL/CSA requirements while supporting RoHS compliance. With No earth/ground wires, it’s suited for installations where a separate grounding Conductor is not required by the design.

Cable Type & Ratings:

• Product Type: SOOW
• Voltage Range: 600V
• Temperature Rating: 90C
• Standards: UL/CSA
• RoHS Compliant: Yes

Conductors:

• Number Of Conductors: 4 Conductor
• Conductor Size: 14 AWG
• Conductor Material: Bare Copper
• Conductor Type: Stranded
• Earth/Ground Wires: No

Materials & Construction:

• Insulation Material: EPR-Ethylene Propylene Rubber
• Jacket Material: CPE Chlorinated Polyethylene
• Jacket Color: Black
• Shielding: Unshielded

Prysmian Group™ and all associated trademarks are the property of their respective owners.
