Prysmian Group 300890.00, 16-1C 19 Stranded TNC Locomotive Polyrad XT 2000V

Part Number: 300890.00

Prysmian Group 300890.00 is a transit/locomotive Wire built with a 16 AWG Stranded, 1 Conductor design for flexible installations. It features thermoset polyolefin Insulation and an XLPO-Cross Linked Polyolefin Jacket for durable performance in demanding environments. This Unshielded construction uses Tinned Or Coated Copper and is rated for 2KV. It meets UL/CSA requirements and is noted for UL VW-1 and IEEE 383 performance.

Conductor:

• Number Of Conductors: 1 Conductor
• Conductor Size: 16 AWG
• Conductor Stranding: Stranded
• Conductor Material: Tinned Or Coated Copper
• Earth/Ground Wires: No

Insulation & Jacket:

• Insulation Material: XLPO-Cross Linked Polyolefin
• Jacket Material: XLPO-Cross Linked Polyolefin
• Insulation Type (Description): Thermoset polyolefin Insulation

Electrical:

• Voltage Range: 2KV

Shielding:

• Shield: Unshielded

Compliance & Standards:

• Standards: UL/CSA
• Flame/Performance: UL VW-1, IEEE 383

Application:

• Product Type: TRANSIT
