Prysmian Group 301260.00, 10-1C 27 Stranded TNC Locomotive Polyrad XT 2000V
Description
Part Number: 301260.00
Prysmian Group 301260.00 is a transit/locomotive Cable built for demanding rail and rolling stock applications, featuring thermoset polyolefin Insulation and Jacket. It uses a 10 AWG, 1 Conductor, Stranded Tinned Or Coated Copper construction for reliable conductivity and flexibility. Designed as an Unshielded Cable with No earth/ground wires, it supports a 2KV voltage range. It is UL listed and meets UL VW-1 and IEEE 383 performance requirements.
Conductor
- Number Of Conductors: 1 Conductor
- Conductor Size: 10 AWG
- Conductor Type: Stranded
- Conductor Material: Tinned Or Coated Copper
- Earth/ground wires: No
Insulation & Jacket
- Insulation Material: XLPO-Cross Linked Polyolefin
- Jacket Material: XLPO-Cross Linked Polyolefin
- Insulation description: Thermoset polyolefin Insulation
Electrical
- Voltage range: 2KV
Compliance & Ratings
- Standards: UL
- Flame Rating: UL VW-1
- Performance standard: IEEE 383
Product Classification
- Product type: Transit
- Shield: Unshielded
Prysmian Group™ and all associated trademarks are the property of their respective owners.
Specifications
| Attribute | Value |
|---|---|
| Priced Per | FT |
Images are for reference only. Specifications may change without notice — verify suitability for your application before purchase. The manufacturer's documentation controls.
