Prysmian Group 7131800, GenSPEED 6 Cat 6 CMP U/UTP Blue

Part Number: 7131800

Prysmian Group GenSPEED 6 Category 6 Cable is a Plenum-rated, Unshielded Twisted Pair solution designed for standards-compliant extended frequency performance. Its unique separator design is engineered to help maintain consistent electrical performance, with performance guaranteed to 350 MHz. This 23 AWG Solid, 4 pair data Cable supports common Ethernet and PoE deployments, including IEEE 802.3: 1000 BASE-T (Gigabit Ethernet), 100 BASE-TX, 10 BASE-T, plus IEEE 802.3af DTE Power (PoE) and IEEE 802.3at for PoE Plus. TRU-Mark print legend contains footage markings from 1000’ to 0’, and the Cable is made in U.S.A.

Key Features:

• Unique separator design engineered for consistent electrical performance
• Performance guaranteed to 350 MHz
• Third-party verified for guaranteed performance
• TRU-Mark print legend contains footage markings from 1000’ to 0’
• Made in U.S.A.

Applications:

• IEEE 802.3: 1000 BASE-T (Gigabit Ethernet), 100 BASE-TX, 10 BASE-T
• ANSI/TIA 854: 1000 BASE-TX
• 155 Mp/s, 1.2 Gb/s ATM
• ANSI X3.263: 100 Mb/s
• IEEE 802.3af DTE Power (PoE)
• IEEE 802.3at for PoE Plus
• Digital Video
• Broadband and Baseband Analog Video

Specifications:

• Category: Category 6
• Cable Type: Data
• Shielding: U/UTP - Unshielded Twisted Pair
• Number of pairs: 4 pair
• Conductor Size: 23 AWG (American Wire Gauge)
• Conductor Type: Solid
• Fire Rating: Plenum
• Jacket Color: Blue
