Prysmian Group 7131900, GenSPEED 6000 Enhanced Cat 6 CMP U/UTP Blue

Part Number: 7131900

Prysmian Group 7131900 GenSPEED 6000 Enhanced Category 6 Cable is designed for high-performance network installations where Plenum-rated CMP construction is required. Its innovative cross-web design maximizes pair separation to help improve key electrical performance parameters and reduce internal crosstalk. Performance is guaranteed to 350 MHz, delivering 5 dB of headroom over the ANSI/TIA 568-C.2 standard for internal crosstalk. Rated to 90C and UL Listed CMP-LP (0.5A), it is able to suport PoE applications up to 100 watts using 50 volts over four pairs, and includes TRU-Mark print legend contains footage markings from 1000’ to 0’.

Key Features:

• Innovative cross-web design allowing for maximum pair separation, increasing key electrical performance parameters
• Performance guaranteed to 350 MHz
• Provides 5 dB of headroom over the ANSI/TIA 568-C.2 standard for internal crosstalk
• Third-party verified for guaranteed prformance
• TRU-Mark print legend contains footage markings from 1000’ to 0’

Construction & Electrical:

• Category: Category 6
• Shielding: U/UTP - Unshielded Twisted Pair
• Conductor Size: 23 AWG (American Wire Gauge)
• Conductor Type: Solid
• Pair Count: 4 PAIR

Ratings & Compliance:

• Fire Rating: Plenum
• Rated temperature: 90C
• UL Listed: CMP-LP (0.5A)

PoE Support:

• Able to suport PoE applications up to 100 watts using 50 volts over four pairs

General:

• Type: Data
• Jacket Color: Blue
