Prysmian Group 7131931, RNB 23-4P UTP CMP Cat 6E FEP FRPVC White

Part Number: 7131931

Prysmian Group 7131931 GenSpeed 6500 Premium Category 6 Cable is a high-performance U/UTP Plenum data Cable engineered with precision balance for added headroom in demanding networks. It features a new and improved separator construction to increase pair separation and deliver optimized performance for bandwidth-intensive applications. Performance is guaranteed to 350 MHz and third-party verified for assured results. The TRU-Mark print legend includes footage markings from 1000’ to 0’, and the Cable is made in U.S.A.

Key features:

• Designed and engineered with precision balance to offer ultimate headroom
• High-end optimized performance to support the most bandwidth-intense applications
• New and improved separator construction allowing for more pair separation
• Performance guaranteed to 350 MHz
• Third-party verified for guaranteed performance
• TRU-Mark print legend contains footage markings from 1000’ to 0’
• Made in U.S.A.

Applications and supported standards:

• IEEE 802.3: 1000 BASE-T (Gigabit Ethernet), 100 BASE-TX, 10 BASE-T
• ANSI/TIA/EIA 854: 1000 BASE-TX
• 155 Mp/s, 1.2 Gb/s ATM
• ANSI X3.263: 100 Mb/s
• IEEE 802.3af DTE Power (PoE)
• IEEE 802.3at for PoE Plus
• Digital Video
• Broadband and Baseband Analog Video

Specifications:

• Category: Category 6
• Type: Data
• Shielding: U/UTP - Unshielded Twisted Pair
• Number of pairs: 4 pair
• Conductor Size: 23 AWG (American Wire Gauge)
• Conductor Type: Solid
• Fire Rating: Plenum
• Jacket Color: White

Prysmian Group™ and all associated trademarks are the property of their respective owners.
