RG214 Cable Stranded 2x97% SCC Braid PVC-II-PVC Jacket Per Foot
Description
RG214 Coaxial Cable is a 50 Ohm cable with a PE Dielectric and an Overall PVC-II-PVC Jacket. It features 2 Silver Plated Copper Braid 96% Each and is listed for Indoor Applications.
Applications
- Use for indoor installations where a coaxial cable is needed.
Specifications
| Attribute | Value |
|---|---|
| Conductor Gauge Size | 13 AWG Str (7x21) SC |
| Conductor Type | Stranded |
| Shield Type | 2 x 96% SCC Braid |
| Jacket Material | Gray PVC-II-PVC Non-Contaminating |
| Conductor Material | Silver Coated Copper |
| Approvals | CL2 |
| O.D. (Inches Nom.) | 0.425 |
| Item Type | RG214 |
| Weight /LBS per 1000FT | 135 |
| Impedance | 50 Ohms |
| Flooded (Y N) | No |
| Outdoor (Y N) | No |
